Characteristic:
●The performance is stable,the brand compressor,built-in security protection,low noise,energy saving and durable.
●The high efficiency:brand water pump,large flow,high efficiency,durability.
●The air-cooled chiller equipped with high precision:precision digital temperature controller,which can accurately control the water temperature.
●Gaoping:steady electrical part adopts the Schneider brand,to ensure that the machine is stable and long life.
●Industrial air-cooled water chiller maintenance convenient:anti electrostatic spray enclosure,the European design and elegant appearance,the outer plate easy disassembly,convenient use and maintenance.
●The free cooling tower,easy installation,convenient movement,suitable for lack of water without cooling tower.
●Industrial air-cooled water chiller low noise fan motor,excellent coolingcooling effect,stable throttling mechanism,excellent anti rust treatment.
Parameters:
| Project Model | TGW-5 | TGW-10 | TGW-15 | TGW-20 | TGW-5T | TGW-10T | TGW-15T | TGW-20T | |
| Power supply | Power specifications | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz |
| Recommended power supply specifications m² | 3×2.5 | 3×4 | 3×6 | 3×10 | 3×2.5 | 3×4 | 3×6 | 3×10 | |
| Kcal/h | 13416 | 26832 | 39990 | 52804 | 13416 | 26832 | 39990 | 52804 | |
| kw | 15.6 | 31.2 | 46.5 | 61.4 | 15.6 | 31.2 | 46.5 | 61.4 | |
| Name | R22/R407C/R410a | ||||||||
| Control method | Capillary tube/thermal expansion valve/electronic expansion valve | ||||||||
| Compressor | Type | Fully enclosed scroll | |||||||
| Power(KW) | 3.75 | 7.5 | 11.2 | 15 | 3.75 | 7.5 | 11.2 | 15 | |
| Quantity (unit) | 1 | 2 | 3 | 4 | 1 | 2 | 3 | 4 | |
| Condenser | Type | Shell tube type | |||||||
| Cooling water pipe diameter(inch) | DN25 | DN40 | DN50 | DN65 | Dn25 | DN40 | DN50 | DN65 | |
| Temperature of the environment | ≤35℃ | ≤35℃ | ≤35℃ | ≤35℃ | ≤35℃ | ≤35℃ | ≤35℃ | ≤35℃ | |
| Bulk water flow (m²h) | 3.35 | 6.71 | 10.00 | 13.20 | 3.35 | 6.71 | 10.00 | 13.20 | |
| Type | Water tank coil type | Shell tube type/shell tube type + water tank | |||||||
| Water tank capacity(L) | 60 | 120 | 190 | 230 | 25 | 60 | 60 | 120 | |
| Frozen water inlet and outlet pipes | DN25 | DN40 | DN50 | DN65 | DN25 | DN40 | DN50 | DN65 | |
| Chilled water flow(m³h) | 2.68 | 5.37 | 8.00 | 10.56 | 2.68 | 5.37 | 8.00 | 10.56 | |
| Type | GD pipeline pump/high pressure multistage pump | ||||||||
| Power(KW) | 0.75 | 0.75 | 1.5 | 2.2 | 0.75 | 0.75 | 1.5 | 2.2 | |
| Flow(Lmin) | 100 | 100 | 225 | 420 | 100 | 100 | 225 | 420 | |
| Unveiling the process(m) | 20 | 18 | 18 | 17 | 20 | 18 | 18 | 21 | |
| Security protection | Panel | 20 | 18 | 18 | 17 | 20 | 18 | 18 | 21 |
| Machine Description | Dimensions(mm) | 950×550×900 | 1310)×750×1250 | 1300×800×1500 | 1530×800×1750 | 950×550×900 | 1310)×750×1250 | 1300×800×1500 | 1530×800×1750 |
| Weight(kg) | 160 | 280 | 380 | 480 | 160 | 280 | 380 | 480 | |
| Surface treatment | Spraying/Painting | Spraying/Painting | Spraying/Painting | Spraying/Painting | Spraying/Painting | Spraying/Painting | Spraying/Painting | Spraying/Painting | |
Application Areas:
Chemical fiber industry:
Freeze relatively dry air and ensure product quality.
Vacuum coating:
It can be used to control the temperature of vacuum coating machines to ensure high quality of plated parts.
Plastic industry:
Accurately control the temperature of each plastic processing, shorten the plastic cycle, and ensure stable quality.
Electroplating industry:
It can control the temperature of electroplating and increase smoothness and density.
Food industry:
Used for high-speed cooling after food processing, so that food can quickly adapt to packaging requirements, in addition to controlling the temperature of fermented food, etc.
Mechanical industry:
Used to control the pressure oil temperature of the hydraulic system, extend service life, improve mechanical lubrication efficiency, and reduce wear.
Construction industry:
Can supply concrete for chilled water, so that the structure of concrete is more in line with construction requirements, effectively enhancing its hardness and toughness.
Electronic industry:
industrial chillers can stabilize the molecular structure of electronic components on the growth line, improve the pass rate, and are mostly used in the ultrasonic cleaning industry to effectively prevent the volatilization of expensive cleaning agents from causing harm to people.
