Characteristic:
● Using efficient unit,according to customer requirements to provide R134A R407C R404A and other environmental refrigerant,unit cooling capacity is higher,the unit occupies a small area,saving space.
●The outstanding combined efficiency will save you 25%energy consumption per year.Double compressor design and "lead-lag"function to extend the operation life of the unit by 50%.
● Stepless cooling capacity regulation,accurate control of frozen water temperature.
●Advanced load balancing principle,main bearing design life up to 100,000 hours.
●Taifeng twin screw compressor has unique flexible characteristics,avoid refrigerant liquid strike,so that it smoothly through the compressor.
●The exhaust of the unit is stable,the noise is low,the vibration is minimal,and the operation is very smooth.
●The function of pre-correction and warning can prevent the chiller from sudden shutdown caused by sudden load increase/decrease.
●Touch type LCD operation screen is easy to operate.
●Cooling/cooling water pump and cooling tower fan can automatically start and stop control,so that the system energy saving operation.
●The controller has advanced energy regulation mode,which can accurately control the outlet temperature of chilled water within the precise range of +0.1C.
●Standard building communication interface to communicate directly with third party control system through open protocol to achieve fast and accurate data transmission.
Parameter:
| Project Type | TLF-100S | TLF-140S | TLF-180S | TLF-200S | TLF-230S | TLF-260S | TLF-310S | TLF-340S | |
| Power supply | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | 3ph-380v/50hz | |
| Cooling capacity | Kcal/h | 86000 | 103200 | 129000 | 154800 | 180600 | 206400 | 258000 | 283800 |
| kw | 100 | 120 | 150 | 180 | 210 | 240 | 300 | 330 | |
| Refrigerant | Name | R22 | R22 | R22 | R22 | R22 | R22 | R22 | R22 |
| Filling amount(KG) | 21.0 | 28.0 | 35.0 | 42.0 | 49.0 | 56.0 | 70.0 | 77.0 | |
| Control method | Expansion valve | Expansion valve | Expansion valve | Expansion valve | Expansion valve | Expansion valve | Expansion valve | Expansion valve | |
| Seat compressor | Type | Semi-sealed female screw type compression cross head | |||||||
| Power(Kw | 22 | 30 | 37 | 45 | 52 | 60 | 74 | 82 | |
| Release method | Y/△Start energy regulation0-25%-50%-75%-100% | ||||||||
| Quantity (unit) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Condenser | Type | Shell tube type high efficiency copper tube | |||||||
| Cooling environment temperature | ≤40℃ | ≤40℃ | ≤40℃ | ≤40℃ | ≤40℃ | ≤40℃ | ≤40℃ | ≤40℃ | |
| Cooling air volume(m²h) | 21.0 | 25.2 | 31.5 | 37.8 | 44.1 | 50.4 | 63.0 | 69.3 | |
| Evaporator | Type | General tube type high efficiency copper tube | |||||||
| Frozen water inlet and outlet pipes | 3" | 3" | 3" | 3" | 4" | 4" | 4" | 5" | |
| Cold water inlet/ outlet temperature | 12℃/17℃ | 12℃/17℃ | 12℃/17℃ | 12℃/17C | 12℃/17℃ | 12℃/17℃ | 12℃/17℃ | 12℃/17℃ | |
| Chilled water flow(m²h) | 17.2 | 20.6 | 25.8 | 31.0 | 36.1 | 41.3 | 51.6 | 56.8 | |
| Security protection | PLC Controller | Bump PC Version | Bump PC Version | Bump PC Version | Bump PC Version | Bump PC Version | Bump PC Version | Bump PC Version | Bump PC Version |
| High and low pressure gauge | Jeff | Jeff | Jeff | Jeff | Jeff | Jeff | Jeff | Jeff | |
| Temperature protector | Japan Brunp | Japan Brunp | Japan Brunp | Japan Brunp | Japan Brunp | Japan Brunp | Japan Brunp | Japan Brunp | |
| Filter | USA ALCO | USA ALCO | USA ALCO | USA ALCO | USA ALCO | USA ALCO | USA ALCO | USA ALCO | |
| Phase sequence relay | French Schneider | French Schneider | French Schneider | French Schneider | French Schneider | French Schneider | French Schneider | French Schneider | |
| Contactor | LS | LS | LS | LS | LS | LS | LS | LS | |
| Main switch | CHINT | CHINT | CHINT | CHINT | CHINT | CHINT | CHINT | CHINT | |
| Machine description | Dimensions(mm) | 2100×950×2150 | 2100×950×2150 | 2400×1200×2150 | 2400×1200×2350 | 3000x1200×2150 | 3000×1200x2300 | 3000×1200×2300 | 4200×2000×2400 |
| Weight（kg) | 1180 | 1380 | 1450 | 1550 | 1800 | 2100 | 2200 | 2560 | |
| Surface treatment | Spraying | Spraying | Spraying | Spraying | Spraying | Spraying | Spraying | Spraying | |
Application Areas:
Chemical fiber industry:
Freeze relatively dry air and ensure product quality.
Vacuum coating:
It can be used to control the temperature of vacuum coating machines to ensure high quality of plated parts.
Plastic industry:
Accurately control the temperature of each plastic processing, shorten the plastic cycle, and ensure stable quality.
Electroplating industry:
It can control the temperature of electroplating and increase smoothness and density.
Food industry:
Used for high-speed cooling after food processing, so that food can quickly adapt to packaging requirements, in addition to controlling the temperature of fermented food, etc.
Mechanical industry:
Used to control the pressure oil temperature of the hydraulic system, extend service life, improve mechanical lubrication efficiency, and reduce wear.
Construction industry:
Can supply concrete for chilled water, so that the structure of concrete is more in line with construction requirements, effectively enhancing its hardness and toughness.
Electronic industry:
industrial chillers can stabilize the molecular structure of electronic components on the growth line, improve the pass rate, and are mostly used in the ultrasonic cleaning industry to effectively prevent the volatilization of expensive cleaning agents from causing harm to people.
