| Model | TCA-2 | TCA-3 | TCA-5 | TCA-10 | TCA-15 | TCA-20 | TCA-30 | TCA-50 |
| Rated Power (HP) | 2 | 3 | 5 | 10 | 15 | 20 | 30 | 50 |
| Temperature Control Range (°C) | 5~35 | 5~35 | 5~35 | 5~35 | 5~35 | 5~35 | 5~35 | 5~35 |
| Cooling Capacity (kW) | 5.7 | 8.6 | 14.5 | 28.2 | 44 | 58.2 | 86.4 | 145 |
| Total Unit Power (kW) | 2.1 | 3 | 4.8 | 9.15 | 14 | 18.4 | 25.3 | 42 |
| Operating Current (A) | 4.5 | 6.5 | 10.2 | 19.5 | 29.8 | 39.2 | 54 | 90 |
| Refrigerant Charge (kg) | 1.2 | 1.8 | 3 | 6 | 9 | 12 | 18 | 30 |
| Refrigerant Type | R22 | R22 | R22 | R22 | R22 | R22 | R22 | R22 |
| Inlet/Outlet Ports (inch) | 1 | 1 | 1 | 1.5 | 1.5 | 2 | 2.5 | 3 |
| Chilled Water Capacity (L) | 23 | 50 | 60 | 120 | 180 | 230 | 320 | 230 |
| Water Pump Flow Rate (L/min) | 50 | 60 | 100 | 100 | 225 | 420 | 420 | 550 |
| Water Pump Head (m) | 13 | 20 | 20 | 18 | 18 | 20 | 18 | 19 |
| Water Pump Power (kW) | 0.35 | 0.4 | 0.75 | 0.75 | 1.5 | 2.2 | 2.2 | 4 |
| Power Supply (V) | 220 | 3N~380V/50HZ | 3N~380V/50HZ | 3N~380V/50HZ | 3N~380V/50HZ | 3N~380V/50HZ | 3N~380V/50HZ | 3N~380V/50HZ |
| Dimensions (mm) | 700*700*525 | 1210*530*1050 | 1370*630*1250 | 1410*750*1500 | 1530*850*1750 | 1710*950*1950 | 1910×1100×2450 | 2210×1210×2170 |
| Weight (kg) | 110 | 135 | 165 | 380 | 450 | 550 | 750 | 1100 |
