Characteristic:
Semi-hermetic Compressor
● Adopted world famous branded semi-hermetic compressors for long term reliable and efficient running;
● Compressor runs with no stage limits to realize stageless continuous adjustment of cooling capacity in between 25%-100% power loaded and maintaining stable outputs;
● Option: HANBELL, BITZER
Shell and Tube Evaporator & Condenser
● Shell and tube condenser adopts high-precision external treaded copper design and shell and tube type evaporator adopts inner treaded copper design, with larger heat exchanging area for higher efficiency and maximizing system performance.
PLC Controller
● Adopted the latest generation PLC controller to realize precision control of the unit, ensuring efficient and stable running;
● Accuracy of outlet chilled water temperature within ±0.5 Celsius degrees;
● Equipped with one week 24 hours timing function to enable automatic operation by appointment;
● Equipped with communication function to realize automatic remote management.
Aviation Hose
● Instead of capillary copper tube, it is resistant to high temperature and high pressure, and will not cause refrigerant leakage due to excessive pressure.
Parameter:
| Refrigerating capacity | KW | 110 | |
| A | 94 | ||
| Power | KW | 4.68 | |
| Electric current | A | 9.5 | |
| Compressor | 1pcs input power | KW | 7.5 |
| 1pcs current operation | A | 15 | |
| Quantity | Set | 3 | |
| Cooling fan | 1pcs input power | KW | 0.97 |
| 1pcs input currnt | A | 1.9 | |
| Quantity | Set | 4 | |
| Refrigerant | Quantity | R22/ R404A/ R507A | |
| Chiller water | Water flow rate | L/min | 316 |
| Inlet | mm | 65 | |
| Circulating water pump | Input power | KW | 2.52 |
| Lift | mH2O | 21 | |
| Evaporator | Type | Shell and tube evaporator | |
| Material | Copper tube | ||
| Evaporation | 10℃ | ||
Application Areas:
Injection Molding Industry
Laser Industry
Electroplating Industry
Hotel Air Conditioning
Medical Industry
Slaughterhouse
Food Processing Industry
Numberical Control Industry
